AMA36 Series

Manufacturer: aimtec

Catalog

AC/DC DESKTOP ADAPTER 12V 36W

Part	Weight	Weight	Approval Agency	Standard Number	Input Connector	Current - Output (Max) [Max]	No Load Power Consumption	Input Type	Polarization	Voltage - Output	Cord Length	Cord Length	Applications	Form	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	Operating Temperature [Max]	Efficiency	Voltage - Input [Max]	Voltage - Input [Min]	Output Connector	Output Connector [diameter]	Output Connector [x]	Region Utilized
aimtec AMA36DR4-120300Y	0.595 lb	270 g	CE FCC UL	60950-1 62368-1	IEC 320-C8	3 A	75 mW	Cord (Sold Separately)	Positive Center	12 V	1.5 m	60.2 in	ITE (Commercial)	Desktop (Class II)	1.33 in	100 mm	33.9 mm	1.97 in	50 mm	3.94 in	36 W	40 °C	Level VI	264 VAC	90 VAC	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	International
aimtec AMA36ER4-120300Y	0.289 lb	131 g	CE UL	60950-1	CEE 7/16	3 A	75 mW	Fixed Blade	Positive Center	12 V	1.5 m	60.2 in	ITE (Commercial)	Wall Mount	3.56 in	83 mm	90.3 mm	1.38 in	35 mm	3.27 in	36 W	40 °C	Level VI	264 VAC	90 VAC	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	Europe
aimtec AMA36UR4-120300Y	0.289 lb	131 g	CE FCC UL	60950-1 62368-1	NEMA 1-15P	3 A	75 mW	Fixed Blade	Positive Center	12 V	1.5 m	60.2 in	ITE (Commercial)	Wall Mount	2.97 in	83 mm	75.5 mm	1.38 in	35 mm	3.27 in	36 W	40 °C	Level VI	264 VAC	90 VAC	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	North America
aimtec AMA36DR4-120250Y	0.595 lb	270 g	CE FCC UL	60950-1 62368-1	IEC 320-C8	2.5 A	100 mW	Cord (Sold Separately)	Positive Center	12 V	1.5 m	60.2 in	ITE (Commercial)	Desktop (Class II)	1.33 in	100 mm	33.9 mm	1.97 in	50 mm	3.94 in	30 Watts	40 °C	Level VI	264 VAC	90 VAC	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	International
aimtec AMA36UR5-120300Y	0.289 lb	131 g	CE FCC UL	60950-1 62368-1	NEMA 1-15P	3 A	75 mW	Fixed Blade	Positive Center	12 V	1.5 m	60.2 in	ITE (Commercial)	Wall Mount	2.97 in	83 mm	75.5 mm	1.38 in	35 mm	3.27 in	36 W	40 °C	Level VI	264 VAC	90 VAC	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	North America
