TEN 30 Series

Catalog

DC DC CONVERTER +/-12V 30W

Part	Applications	Number of Outputs	Voltage - Isolation	Voltage - Input (Min) [Min]	Size / Dimension	Mounting Type	Features	Type	Voltage - Input (Max) [Max]	Package / Case	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Voltage - Output 2	Current - Output (Max)	Efficiency	Supplier Device Package	Voltage - Output 3	Current - Output (Max)	Current - Output (Max)	Current - Output (Max) [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]
Traco Power TEN 30-2422	ITE (Commercial)	2	1.5 kV	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	36 V	6-DIP Module	12 V	-40 °C	85 °C	30 Watts	-12 V	1.25 A	89 %	Module
Traco Power TEN 30-2431WIN	ITE (Commercial)	3	1.5 kV	9 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	36 V	7-DIP Module 6 Leads	5 V	-40 °C	75 °C	30 Watts	12 V	4 A	88 %	Module	-12 V	416 mA	416 mA
Traco Power TEN 30-1211	ITE (Commercial)	1	1.5 kV	9 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	18 V	6-DIP Module	5.1 V	-40 °C	85 °C	31 W			87 %	Module				6 A
Traco Power TEN 30-1223	ITE (Commercial)	2	1.5 kV	9 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	18 V	6-DIP Module	15 V	-40 °C	85 °C	30 Watts	-15 V	1 A	87 %	Module
Traco Power TEN 30-4812WIN	ITE (Commercial)	1	1.5 kV	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	75 V	7-DIP Module 6 Leads	12 V	-40 °C	75 °C	30 Watts			90 %	Module				2.5 A
Traco Power TEN 30-4810WI	ITE (Commercial)	1	1.5 kV	18 V		Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	75 V	7-DIP Module 6 Leads	3.3 V	-40 °C	85 °C	20 W			87 %					6 A	2 in	0.4 "	10.2 mm	50.8 mm	1.6 in	40.6 mm
Traco Power TEN 30-4810WIN	ITE (Commercial)	1	1.5 kV	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP	Isolated Module	75 V	6-DIP Module	3.3 V	-40 C	75 ░C	25 W			86 %	Module				7.5 A
Traco Power TEN 30-4811WIN	ITE (Commercial)	1	1.5 kV	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	75 V	7-DIP Module 6 Leads	5.1 V	-40 °C	75 °C	31 W			88 %	Module				6 A
Traco Power TEN 30-4821	ITE (Commercial)	2	1.5 kV	36 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	75 V	6-DIP Module	5 V	-40 °C	85 °C	30 Watts	-5 V	3 A	90 %	Module
Traco Power TEN 30-4822WIN	ITE (Commercial)	2	1.5 kV	18 V	0.4 in 10.2 mm 25.4 mm 50.8 mm	Through Hole	OCP OTP OVP Remote On/Off SCP UVLO	Isolated Module	75 V	7-DIP Module 6 Leads	12 V	-40 °C	75 °C	30 Watts	-12 V	1.25 A	88 %	Module
