uvr Series
Manufacturer: Nichicon
Beta
⌘K
ELECTROLYTIC CAPACITOR, MINIATURE, 6800 ΜF, 10 V, ± 20%, 2000 HOURS @ 85°C, POLAR
| Part | Package / Case | Ripple Current @ High Frequency | Mounting Type | Polarization | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [diameter] | Size / Dimension [diameter] | Lifetime @ Temp. | Ripple Current @ Low Frequency | Lead Spacing | Lead Spacing | Tolerance | Voltage - Rated | Capacitance | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nichicon | Can Radial | 2.5875 A | Through Hole | Polar | General Purpose | 85 °C | -40 C | 0.63 in | 16 mm | 2000 Hrs | 2.25 A | 0.295 in | 7.5 mm | 20 % | 10 V | 6800 µF | 1.063 in | 27 mm |
 Nichicon | Can Radial | 2.277 A | Through Hole | Polar | General Purpose | 85 °C | -40 C | 0.63 in | 16 mm | 2000 Hrs | 1.98 A | 0.295 in | 7.5 mm | 20 % | 25 VDC | 3.3 mF | 1.063 in | 27 mm |
