EPC23103 Series
Manufacturer: EPC
Beta
⌘K
IC GAN EPOWER STAGE 100V 20A
| Part | Current - Peak Output | Mounting Type | Interface | Applications | Fault Protection | Package / Case | Voltage - Supply [Max] | Voltage - Supply [Min] | Load Type | Rds On (Typ) | Voltage - Load [Min] | Voltage - Load [Max] | Current - Output / Channel | Features | Operating Temperature [Min] | Operating Temperature [Max] | Technology |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
109 A | Surface Mount Wettable Flank | Logic | DC Motors DC-DC Converters | ESD Over Voltage Short Circuit | 13-PowerWFQFN | 80 V | 10 VDC | Capacitive and Resistive | 7.6 mOhm | 10 V | 80 V | 25 A | Bootstrap Circuit Slew Rate Controlled | -40 C | 125 °C | Gallium Nitride (GaN) FETs |
