STA8090GA Series

Automotive Grade GPS/Galileo/Glonass/Beidou/QZSS receiver

Catalog

Automotive Grade GPS/Galileo/Glonass/Beidou/QZSS receiver

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Supplier Device Package	Package / Case	Frequency [Min]	Frequency [Max]	Qualification	Mounting Type	Data Interface	Modulation or Protocol	Grade	Antenna Connector	Memory Size	Operating Temperature [Max]	Operating Temperature [Min]	Sensitivity	Applications	Data Rate (Max)
STMicroelectronics STA8090GATR	1.26 V	1.08 V	56-VFQFPN (7x7)	56-VFQFN Exposed Pad	4.092 MHz 8.57 MHz 10.23 MHz	1.561 GHz 1.575 GHz 1.601 GHz	AEC-Q100	Surface Mount	I2C SPI UART USB	BeiDou Galileo GLONASS GNSS GPS	Automotive	PCB Surface Mount	256 kB 512 kB	85 C	-40 ¯C	-162 dBm	GPS Receiver	12 Mbps

Catalog

Automotive Grade GPS/Galileo/Glonass/Beidou/QZSS receiver

Description

STA8090GA belongs to Teseo III family products. STA8090GA is a single die standalone positioning receiver IC working on multiple constellations (GPS/Galileo/GLONASS/BeiDou/QZSS). The device is offered with a complete GNSS firmware which performs all GNSS operations including tracking, acquisition, navigation and data output. STA8090GA is compliant with ST Automotive Grade qualification which includes in addition to AEC-Q100 requirements a set of production flow methodologies targeting zero defect per million. STA8090GA, fulfilling high quality and service level requirements of the Automotive market, is the ideal solution for in-dash navigation, smart antenna, car to car, V2X and OEM telematics applications. STA8090GAD can run also TESEO-DRAW the STMicroelectronics dead reckoning firmware.
