UPM Series

Manufacturer: Nichicon

Catalog

CAP ALUMINUM LYTIC 220UF 63V 20% (16 X 15MM) RADIAL 7.5MM 0.82A 5000H 105°C AMMO AUTOMOTIVE AEC-Q200

Part	Ratings	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Ripple Current @ Low Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Capacitance	Voltage - Rated	Package / Case	Polarization	Impedance	Tolerance	Ripple Current @ High Frequency	Applications	Lifetime @ Temp.	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [z]
Nichicon UPM1J221MHD6TN	AEC-Q200	Through Hole	0.669 "	17 mm	0.295 in	7.5 mm	820 mA	0.63 in	16 mm	220 µF	63 V	Can Radial	Polar	70 mOhms	20 %	1.12 A	Automotive	5000 Hrs	-55 C	105 ░C
Nichicon UPM1A152MHD6TN	AEC-Q200	Through Hole	0.669 "	17 mm	0.295 in	7.5 mm	1.19 A	0.63 in	16 mm	1.5 mF	10 V	Can Radial	Polar	50 mOhms	20 %	1.33 A	Automotive	5000 Hrs	-55 C	105 ░C
Nichicon UPM2G010MPD	AEC-Q200	Through Hole		14.5 mm	0.197 "	5 mm	17 mA	0.394 in	10 mm	1 µF	400 V	Can Radial	Polar		20 %	27.2 mA	Automotive	5000 Hrs	-40 C	105 ░C	0.571 "
Nichicon UPM1A222MHD6TN	AEC-Q200	Through Hole	0.669 "	17 mm	0.295 in	7.5 mm	1.44 A	0.709 in	18 mm	2200 µF	10 V	Can Radial	Polar	39 mOhms	20 %	1.6 A	Automotive	5000 Hrs	-55 C	105 ░C
Nichicon UPM1K391MHD6TN	AEC-Q200	Through Hole			0.295 in	7.5 mm	1.12 A	0.709 in	18 mm	390 µF	80 V	Can Radial	Polar	89 mOhms	20 %	1.45 A	Automotive	5000 Hrs	-55 C	105 ░C		0.866 in	22 mm
Nichicon UPM1V681MHD1TO	AEC-Q200	Through Hole		27 mm	0.197 "	5 mm	1.41 A	0.492 in	12.5 mm	680 µF	35 V	Can Radial	Polar	36 mOhms	20 %	1.7 A	Automotive	5000 Hrs	-55 C	105 ░C	1.063 in
Nichicon UPM1C102MPD1AA	AEC-Q200	Through Hole		32.5 mm	0.197 "	5 mm	1.22 A	0.394 in	10 mm	1000 µF	16 V	Can Radial	Polar	47 mOhms	20 %	1.41 A	Automotive	5000 Hrs	-55 C	105 ░C	1.28 in
Nichicon UPM1V182MHD6	AEC-Q200	Through Hole		27 mm	0.295 in	7.5 mm	2.11 A	0.709 in	18 mm	1800 µF	35 V	Can Radial	Polar	25 mOhms	20 %	2.35 A	Automotive	5000 Hrs	-55 C	105 ░C	1.063 in
Nichicon UPM1C221MPD	AEC-Q200	Through Hole	0.512 "		0.138 in	3.5 mm	335 mA	0.315 in	8 mm	220 µF	16 V	Can Radial	Polar	0.16 Ohms	20 %		Automotive	3000 Hrs	-55 C	105 ░C				13 mm
Nichicon UPM1A222MHD1AA	AEC-Q200	Through Hole		27 mm	0.197 "	5 mm	1.53 A	0.492 in	12.5 mm	2.2 mF	10 V	Can Radial	Polar	34 mOhms	20 %	1.71 A	Automotive	5000 Hrs	-55 C	105 ░C	1.063 in
