GRN-60 Series

Catalog

GRN-60-1008 CHCO

Part	Mounting Type	Applications	Voltage - Output 1	Features	Standard Number	Type	Power (Watts)	Approval Agency	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Current - Output 1	Efficiency	Number of Outputs
Integrated Power Designs 1011360CHCO	Chassis Mount	ITE (Commercial) Medical	19 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Enclosed	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	3.1 A	87 %	1
Integrated Power Designs 1011333CH	Chassis Mount	ITE (Commercial) Medical	12 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	5 A	87 %	1
Integrated Power Designs 1011331CHCO	Chassis Mount	ITE (Commercial) Medical	3.3 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Enclosed	30 Watts	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	9 A	80 %	1
Integrated Power Designs 1011401CH	Chassis Mount	ITE (Commercial) Medical	3.3 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	30 Watts	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	9 A	80 %	1
Integrated Power Designs 1011406CHCO	Chassis Mount	ITE (Commercial) Medical	28 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Enclosed	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	2.2 A	87 %	1
Integrated Power Designs 1011335CH	Chassis Mount	ITE (Commercial) Medical	24 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	2.5 A	87 %	1
Integrated Power Designs 1011336CH	Chassis Mount	ITE (Commercial) Medical	28 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	2.2 A	87 %	1
Integrated Power Designs 1011408CH	Chassis Mount	ITE (Commercial) Medical	19 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	3.1 A	87 %	1
Integrated Power Designs 1011334CH	Chassis Mount	ITE (Commercial) Medical	15 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Chassis	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	4 A	87 %	1
Integrated Power Designs 1011334CHCO	Chassis Mount	ITE (Commercial) Medical	15 V	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	Enclosed	60 W	CE cURus TUV UKCA	70 °C	81.3 mm	1.28 "	81.28 mm	32.5 mm	61.7 mm	2.43 in	4 A	87 %	1
