396-092 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 92POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Termination | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Read Out | Number of Rows [custom] | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Gender | Card Type | Mounting Type | Number of Positions | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Wire Wrap | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Through Hole | 92 | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder Wire Wrap | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Right Angle Through Hole | 92 | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder Wire Wrap | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Right Angle Through Hole | 92 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Flush Mount M3 Threaded Insert Top Opening | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Through Hole | 92 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | 4-40 Threaded Insert Top Mount Opening | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Board Edge Straddle Mount | 92 | Card Extender Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Through Hole | 92 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder Eyelet(s) | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Board Edge Straddle Mount | 92 | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Through Hole | 92 | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Through Hole | 92 | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Solder | 3.18 mm | 0.125 in | -40 C | 105 ░C | Copper Alloy | Gold | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Black | 0.25 Ám | 10 Áin | Cantilever | Dual | 2 | 46 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Board Edge Straddle Mount | 92 | Card Extender |
