Super Fast Recovery Diode
Description
AI
RFV12TJ6S is the silicon epitaxial planar type Fast Recovery Diode for PFC.
Beta
⌘K
Super Fast Recovery Diode
Super Fast Recovery Diode
| Part | Voltage - Forward (Vf) (Max) @ If | Current - Average Rectified (Io) | Technology | Reverse Recovery Time (trr) | Voltage - DC Reverse (Vr) (Max) [Max] | Supplier Device Package | Mounting Type | Package / Case | Current - Reverse Leakage @ Vr | Operating Temperature - Junction [Max] | Speed | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 2.8 V | 12 A | Standard | 45 ns | 600 V | TO-220ACFP | Through Hole | TO-220-2 | 10 µA | 150 °C | 200 mA 500 ns | |
 Rohm Semiconductor | 2.8 V | 12 A | Standard | 45 ns | 600 V | TO-220ACFP | Through Hole | TO-220-2 Full Pack | 10 µA | 200 mA 500 ns | 150 ¯C |
