BAS70 Series

Catalog

70 V, 70 MA RF AND ULTRAFAST SWITCHING SIGNAL SCHOTTKY DIODE

Part	Current - Average Rectified (Io) (per Diode)	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]	Speed	Speed	Current - Reverse Leakage @ Vr	Package / Case	Technology	Voltage - Forward (Vf) (Max) @ If	Diode Configuration	Supplier Device Package	Operating Temperature - Junction [Max]	Capacitance @ Vr, F	Current - Average Rectified (Io)
STMicroelectronics BAS70-05FILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-59 SOT-23-3 TO-236-3	Schottky	1 V	1 Pair Common Cathode	SOT-23-3	150 °C
STMicroelectronics BAS70JFILM		Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-76 SOD-323	Schottky	1 V		SOD-323	150 °C	2 pF	70 mA
STMicroelectronics BAS70KFILM		Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-79 SOD-523	Schottky	1 V		SOD-523	150 °C	2 pF	70 mA
STMicroelectronics BAS70-08SFILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	6-TSSOP SC-88 SOT-363	Schottky	1 V	3 Independent	SOT-323-6L	150 °C
STMicroelectronics BAS70FILM		Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-59 SOT-23-3 TO-236-3	Schottky	1 V		SOT-23-3	150 °C	2 pF	70 mA
STMicroelectronics BAS70ZFILM		Surface Mount	70 V	200 mA	Any Speed	10 µA	SOD-123	Schottky	1 V		SOD-123	150 °C	2 pF	70 mA
STMicroelectronics BAS70-04WFILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-70 SOT-323	Schottky	1 V	1 Pair Series Connection	SOT-323	150 °C
STMicroelectronics BAS70-06FILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-59 SOT-23-3 TO-236-3	Schottky	1 V	1 Pair Common Anode	SOT-23-3	150 °C
STMicroelectronics BAS70-04FILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-59 SOT-23-3 TO-236-3	Schottky	1 V	1 Pair Series Connection	SOT-23-3	150 °C
STMicroelectronics BAS70-05WFILM	70 mA	Surface Mount	70 V	200 mA	Any Speed	10 µA	SC-70 SOT-323	Schottky	1 V	1 Pair Common Cathode	SOT-323-3	150 °C
