2404KL Series

Catalog

FAN AXIAL 60X10.3MM 12VDC WIRE

Part	Material - Frame	Air Flow	Air Flow	Material - Blade	Voltage Range [Min]	Voltage Range [Max]	Current Rating (Amps)	Termination	RPM	Size / Dimension [z]	Size / Dimension [x]	Power (Watts)	Fan Type	Static Pressure	Static Pressure	Width [x]	Features	Approval Agency	Weight [diameter]	Weight [diameter]	Noise	Bearing Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated
NMB TECHNOLOGIES 2404KL-04W-B49-B50	Plastic	0.454 m³/min	16.2 CFM	Plastic	10.2 VDC	13.8 VDC	0.2 A	3 Wire Leads	4200 RPM	60 mm	60 mm	2.4 W	Tubeaxial	23 Pa	0.092 in H2O	10.3 mm	Speed Sensor (Tach)	CE CSA UL VDE	0.055 lb	24.95 g	33 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B49-B00	Plastic	0.454 m³/min	16.2 CFM	Plastic	10.2 VDC	13.8 VDC	0.2 A	3 Wire Leads	4200 RPM	60 mm	60 mm	2.4 W	Tubeaxial	23 Pa	0.092 in H2O	10.3 mm	Locked Rotor Sensor	CE CSA UL VDE	0.055 lb	24.95 g	33 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B30-B00	Plastic	0.384 mł/min	13.7 CFM	Plastic	10.2 VDC	13.8 VDC	100 mA	2 Wire Leads	3600 RPM	60 mm	60 mm	1.2 W	Tubeaxial	16.7 Pa	0.067 in H2O	10.3 mm		CE CSA UL VDE	0.055 lb	24.95 g	29 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B39-B50	Plastic	0.384 mł/min	13.7 CFM	Plastic	10.2 VDC	13.8 VDC	100 mA	3 Wire Leads	3600 RPM	60 mm	60 mm	1.2 W	Tubeaxial	16.7 Pa	0.067 in H2O	10.3 mm	Speed Sensor (Tach)	CE CSA UL VDE	0.055 lb	24.95 g	29 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B39-B00	Plastic	0.384 mł/min	13.7 CFM	Plastic	10.2 VDC	13.8 VDC	100 mA	3 Wire Leads	3600 RPM	60 mm	60 mm	1.2 W	Tubeaxial	16.7 Pa	0.067 in H2O	10.3 mm	Locked Rotor Sensor	CE CSA UL VDE	0.055 lb	24.95 g	29 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B59-B00	Plastic	0.532 m³/min	19 CFM	Plastic	10.2 VDC	13.8 VDC	270 mA	3 Wire Leads	4800 RPM	60 mm	60 mm	3.24 W	Tubeaxial	30.1 Pa	0.121 in H2O	10.3 mm	Locked Rotor Sensor	CE CSA UL VDE	0.055 lb	24.95 g	36 dB	Ball	60 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B40-B00	Plastic	0.454 m³/min	16.2 CFM	Plastic	10.2 VDC	13.8 VDC	0.2 A	2 Wire Leads	4200 RPM	60 mm	60 mm	2.4 W	Tubeaxial	23 Pa	0.092 in H2O	10.3 mm		CE CSA UL VDE	0.055 lb	24.95 g	33 dB(A)	Ball	70 °C	-10 °C	12 VDC
NMB TECHNOLOGIES 2404KL-04W-B59-B50	Plastic	0.532 m³/min	19 CFM	Plastic	10.2 VDC	13.8 VDC	270 mA	3 Wire Leads	4800 RPM	60 mm	60 mm	3.24 W	Tubeaxial	30.1 Pa	0.121 in H2O	10.3 mm	Speed Sensor (Tach)	CE CSA UL VDE	0.055 lb	24.95 g	36 dB	Ball	60 °C	-10 °C	12 VDC
