AM8TW Series
Manufacturer: aimtec
Beta
⌘K
MODULE DC-DC 24V/48VIN 2-OUT -12V/12V -0.335A/0.335A 8W 8-PIN
| Part | Package / Case | Power (Watts) | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Current - Output (Max) [Min] | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] | Features | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Number of Outputs | Voltage - Input (Max) [Max] | Type | Mounting Type | Efficiency | Voltage - Isolation | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | 24-DIP Module | 8 W | CE cURus | 85 °C | -40 C | ITE (Commercial) | 335 mA | 335 mA | 13 V | -12 V | 12 V | Remote On/Off | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 2 | 70 V | Isolated Module | Through Hole | 85 % | 3000 V | -12 V |
