LGW Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 450VOLTS 180UF SNAP-IN

Part	Ripple Current @ Low Frequency	Mounting Type	Ripple Current @ High Frequency	Tolerance	Capacitance	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Polarization	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Voltage - Rated	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension
Nichicon LGW2W181MELZ45	1.35 A	Through Hole	1.9305 A	20 %	180 µF	3000 Hrs	105 ░C	-25 °C	Radial Can - Snap-In	Polar	0.394 in	10 mm	0.866 "	22 mm	1.772 "	45 mm	450 V	General Purpose
Nichicon LGW2W391MELB50	2.4 A	Through Hole	3.432 A	20 %	390 µF	3000 Hrs	105 ░C	-25 °C	Radial Can - Snap-In	Polar	0.394 in	10 mm	1.181 "				450 V	General Purpose	1.969 in	50 mm	30 mm
Nichicon LGW2D182MELC40	4.62 A	Through Hole	6.93 A	20 %	1800 µF	3000 Hrs	105 ░C	-40 C	Radial Can - Snap-In	Polar	0.394 in	10 mm	1.378 "	35 mm			200 VDC	General Purpose	1.575 in	40 mm
Nichicon LGW2D102MELA45	3.45 A	Through Hole	5.175 A	20 %	1000 µF	3000 Hrs	105 ░C	-40 C	Radial Can - Snap-In	Polar	0.394 in	10 mm	0.984 "	25 mm	1.772 "	45 mm	200 VDC	General Purpose
Nichicon LGW2D122MELA50	3.98 A	Through Hole	5.97 A	20 %	1.2 mF	3000 Hrs	105 ░C	-40 C	Radial Can - Snap-In	Polar	0.394 in	10 mm	0.984 "	25 mm			200 VDC	General Purpose	1.969 in	50 mm
Nichicon LGW2W271MELA50	1.74 A	Through Hole	2.4882 A	20 %	270 µF	3000 Hrs	105 ░C	-25 °C	Radial Can - Snap-In	Polar	0.394 in	10 mm	0.984 "	25 mm			450 V	General Purpose	1.969 in	50 mm
