Pch -80V -10A, HSMT8, Power MOSFET
Description
AI
RQ3N040AT is a power MOSFET with low-on resistance and High power package, suitable for switching and motor drives.
Beta
⌘K
Pch -80V -10A, HSMT8, Power MOSFET
Pch -80V -10A, HSMT8, Power MOSFET
| Part | Power Dissipation (Max) | Mounting Type | Drain to Source Voltage (Vdss) | Technology | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) @ 25°C | Gate Charge (Qg) (Max) @ Vgs [Max] | FET Type | Package / Case | Operating Temperature | Input Capacitance (Ciss) (Max) @ Vds [Max] | Supplier Device Package [x] | Supplier Device Package [custom] | Supplier Device Package [y] | Rds On (Max) @ Id, Vgs | Vgs (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 2 W 15 W | Surface Mount | 80 V | MOSFET (Metal Oxide) | 6 V 10 V | 4 A 10 A | 22 nC | P-Channel | 8-PowerVDFN | 150 °C | 930 pF | 3.2 | 8-HSMT | 3 | 126 mOhm | 20 V |
