E3612S Series

Catalog

CABLE 2COND 16AWG ORANGE SHLD

Part	Shield Type	Cable Type	Usage	Conductor Strand	Jacket (Insulation) Material	Jacket (Insulation) Diameter	Jacket (Insulation) Diameter	Features	Length	Length	Conductor Insulation	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Wire Gauge	Conductor Material	Jacket Color	Number of Conductors	Voltage	Operating Temperature [Max]	Shield Material	Length [x]	Length [x]	Shield Coverage
Prysmian Group E3612S.41.04	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Orange	2	300 VDC	75 ░C
Prysmian Group E3612S.41.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C	Flexfoil®	100 ft	30.5 m	100 %
Prysmian Group E3612S.41.07	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Blue	2	300 VDC	75 ░C
Prysmian Group E3612S.18.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	152.4 m	500 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C	Flexfoil®			100 %
Prysmian Group E3612S.41.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C		100 ft	30.5 m
Prysmian Group E3612S.44.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	762 m	2500 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C
Prysmian Group E3612S.41.04	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Orange	2	300 VDC	75 ░C	Flexfoil®			100 %
Prysmian Group E3612S.18.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	152.4 m	500 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C
Prysmian Group E3612S.41.07	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Blue	2	300 VDC	75 ░C	Flexfoil®			100 %
Prysmian Group E3612S.44.03	Foil	Multi-Conductor	Alarm Safety	Solid	Plenum Poly-Vinyl Chloride (PVC)	0.173 "	4.39 mm	Drain Wire Rip Cord	762 m	2500 ft	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	16 AWG	Copper Bare	Red	2	300 VDC	75 ░C	Flexfoil®			100 %
