NCP3284 Series

4.5V to 18V, 30A(NCP3284)/ 35A(NC3284A) Highly efficient, DC/DC Converter in thermally enhanced 5mm by 6mm package

Catalog

4.5V to 18V, 30A(NCP3284)/ 35A(NC3284A) Highly efficient, DC/DC Converter in thermally enhanced 5mm by 6mm package

Part	Voltage - Output (Min/Fixed)	Number of Outputs	Topology	Package / Case	Voltage - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Function	Synchronous Rectifier	Output Configuration	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Mounting Type	Frequency - Switching	Output Type	Current - Output
ON Semiconductor NCP3284DMNTXG
ON Semiconductor NCP3284MNTXG	0.8 V	1	Buck	37-PowerWFQFN	15.3 V	18 V	4.5 V	Step-Down		Positive	-40 °C	100 °C	37-PQFN (5x6)	Surface Mount	1 MHz 500 kHz 600 kHz 800 kHz	Adjustable	30 A

Catalog

4.5V to 18V, 30A(NCP3284)/ 35A(NC3284A) Highly efficient, DC/DC Converter in thermally enhanced 5mm by 6mm package

Key Features

• High Efficiency

• Fast Load Transient

• Frequency Selection

• 0.6% accurate reference

• Remote Sense

• Enable Input and Power Good Indicator

• Adjustable Current Limit

• Adjustable Soft Start

• Thermally enhanced QFN package

• Specified from -40℃ to 125℃

Description

The NCP3284/A is a 30A/35A POL targeted for applications requiring high efficiency in a small board footprint. This device integrates a dc/dc controller with two highly efficient mosfets into a signal thermally enhanced 5mm by 6mm QFN package. It utilizes a patented enhanced ramp pulse modulation control architecture that delivers ultra-fast load transients that enable the reduction of external capacitors and/or provide better transient tolerances. The new architecture also improved load regulation versus traditional constant on time controllers.
