MDF14A Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONNECTOR
| Part | Contact Material | Fastening Type | Termination | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Style | Number of Rows | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Shape | Shrouding | Contact Type | Mounting Type | Insulation Material | Material Flammability Rating | Insulation Color | Contact Finish - Post | Number of Positions Loaded | Number of Positions | Contact Length - Post | Contact Length - Post | Voltage Rating | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | ||||||||||||||||||||||||||
Hirose Electric Co Ltd | ||||||||||||||||||||||||||
Hirose Electric Co Ltd | Brass | Push-Pull | Solder | 0.217 in | 5.51 mm | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Nylon Polyamide (PA) | UL94 V-0 | Beige | Tin | All | 8 | ||||
 Hirose Electric Co Ltd | Copper | Push-Pull | Solder | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Liquid Crystal Polymer (LCP) | UL94 V-0 | Black | Tin | All | 6 | 0.13 " | 3.3 mm | 250 VAC | 5 A | ||
Hirose Electric Co Ltd | Brass | Push-Pull | Solder | 0.217 in | 5.51 mm | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Nylon Polyamide (PA) | UL94 V-0 | Beige | Tin | All | 7 | ||||
Hirose Electric Co Ltd | Brass | Push-Pull | Solder | 0.217 in | 5.51 mm | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Nylon Polyamide (PA) | UL94 V-0 | Beige | Tin | All | 9 | ||||
Hirose Electric Co Ltd | Brass | Push-Pull | Solder | 0.217 in | 5.51 mm | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Nylon Polyamide (PA) | UL94 V-0 | Beige | Tin | All | 4 | ||||
Hirose Electric Co Ltd | Brass | Push-Pull | Solder | 0.217 in | 5.51 mm | 2.5 mm | 0.098 in | Board to Cable/Wire | 1 | Header | -55 C | 125 °C | Square | Shrouded - 4 Wall | Male Pin | Right Angle Through Hole | Nylon Polyamide (PA) | UL94 V-0 | Beige | Tin | All | 5 |
