TRI 20 Series

Catalog

DC DC CONVERTER 24V 20W

Part	Mounting Type	Efficiency	Package / Case	Power (Watts)	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Voltage - Isolation	Approval Agency	Voltage - Input (Min) [Min]	Number of Outputs	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Voltage - Output 1	Type	Voltage - Output 2
Traco Power TRI 20-4815	Through Hole	89 %	5-DIP Module 4 Leads	20 W	840 mA	75 V	8 kV	CB cURus	36 V	1	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	24 V	Isolated Module
Traco Power TRI 20-4822	Through Hole	89 %	5-DIP Module	20 W	840 mA	75 V	8 kV	CB cURus	36 V	2	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	12 V	Isolated Module	-12 V
Traco Power TRI 20-1222	Through Hole	89 %	5-DIP Module	20 W	840 mA	18 V	8 kV	CB cURus	9 V	2	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	12 V	Isolated Module	-12 V
Traco Power TRI 20-1215	Through Hole	89 %	5-DIP Module 4 Leads	20 W	840 mA	18 V	8 kV	CB cURus	9 V	1	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	24 V	Isolated Module
Traco Power TRI 20-2411	Through Hole	87 %	5-DIP Module 4 Leads	20 W	4 A	36 V	8 kV	CB cURus	18 V	1	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	5.1 V	Isolated Module
Traco Power TRI 20-2412	Through Hole	88 %	5-DIP Module 4 Leads	20 W	1.67 A	36 V	8 kV	CB cURus	18 V	1	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	12 V	Isolated Module
Traco Power TRI 20-4813	Through Hole	90 %	5-DIP Module 4 Leads	20 W	1.333 A	75 V	8 kV	CB cURus	36 V	1	ITE (Commercial)	-40 C	76 °C	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	15 V	Isolated Module
