TM2RE Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN MOD JACK 6P4C R/A UNSHLD
| Part | Housing Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Contact Material | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] | Termination | Contact Finish | Mounting Type | Shielding | Number of Ports | LED Color | Features | Tab Direction | Connector Type | Orientation | Orientation | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Orientation [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 4 | 6 | Solder | Gold | Through Hole | Unshielded | 3 | Does Not Contain LED | Board Lock Panel Stops | Up | Jack | 90 ° | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 4 | 6 | Solder | Gold | Through Hole | Unshielded | 2 | Does Not Contain LED | Board Lock | User Selectable | Jack | Vertical | ||||||
 Hirose Electric Co Ltd | -25 °C | 80 °C | 1 | Solder | Gold | Through Hole | Unshielded | 4 | Does Not Contain LED | Board Lock | Up | Jack | 90 ° | 50 µin | 1.27 µm | 4 contacts | 4 positions | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | Solder | Gold | Through Hole | Unshielded | 3 | Does Not Contain LED | Board Lock Panel Stops | Up | Jack | 90 ° | 2 | 6 | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 4 | 6 | Solder | Gold | Through Hole | Unshielded | 2 | Does Not Contain LED | Board Lock Panel Stops | Up | Jack | 90 ° | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | Solder | Gold | Through Hole | Unshielded | 4 | Does Not Contain LED | Board Lock | User Selectable | Jack | Vertical | 2 | 6 | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 4 | 6 | Solder | Gold | Through Hole | Unshielded | 4 | Does Not Contain LED | Board Lock | User Selectable | Jack | Vertical | ||||||
Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | Solder | Gold | Through Hole | Unshielded | 3 | Does Not Contain LED | Board Lock Panel Stops | Up | Jack | 90 ° | 50 µin | 1.27 µm | 2 | 6 | 90 ░ | |||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 6 | 6 | Solder | Gold | Through Hole | Unshielded | 2 | Does Not Contain LED | Board Lock | User Selectable | Jack | Vertical | ||||||
 Hirose Electric Co Ltd | Polybutylene Terephthalate (PBT) | -25 °C | 80 °C | 1 | Phosphor Bronze | 6 | 6 | Solder | Gold | Through Hole | Unshielded | 1 | Does Not Contain LED | Board Lock | User Selectable | Jack | Vertical |
