9.25 GHz to 10.10 GHz MMIC VCO with Half Frequency Output
Key Features
• Dual outputfOUT= 9.25 GHz to 10.10 GHzfOUT/2 = 4.625 GHz to 5.050 GHz
• Power output (POUT): 11 dBm (typical)
• Single-sideband (SSB) phase noise: −115 dBc/Hz at 100 kHz
• No external resonator needed
• RoHS-compliant, 5 mm × 5 mm LFCSP: 25 mm2
Description
AI
The HMC1162 is a monolithic microwave integrated circuit (MMIC), voltage controlled oscillator (VCO) that integrates the resonator, a negative resistance device, and varactor diodes, and features a half frequency output.Because of the monolithic construction of the oscillator, the output power and phase noise performance are excellent over temperature.The power output is 11 dBm typical from a 5 V supply voltage. The VCO is housed in a RoHS-compliant, 32-lead LFCSP and requires no external matching components.APPLICATIONSPoint to point and multipoint radiosTest equipment and industrial controlsVery small aperture terminals (VSATs)
