PSAC12R Series

Wall Mount AC Adapters 12W 7.5V 1.6A Levl VI 2.1 No Blade

Manufacturer: Phihong USA

Catalog

Wall Mount AC Adapters 12W 7.5V 1.6A Levl VI 2.1 No Blade

Catalog

Wall Mount AC Adapters 12W 7.5V 1.6A Levl VI 2.1 No Blade

Part	Power (Watts)	Region Utilized	Voltage - Input [Max]	Voltage - Input [Min]	Output Connector [x]	Output Connector [diameter]	Output Connector	Form	Input Type	No Load Power Consumption	Voltage - Output	Approval Agency	Current - Output (Max) [Max]	Applications	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Weight [custom]	Weight [custom]	Cord Length	Cord Length	Efficiency	Input Connector	Standard Number
Phihong USA PSAC12R-060	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	6 V	C-Tick CB CE cULus	2 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-240	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	24 V	C-Tick CB CE cULus	500 mA	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-120-R-CR1	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug R/A	Wall Mount	Multi-Blade (Sold Separately)	100 mW	12 V	AS/NZS cULus IEC PSE	1 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade	55022 60950-1
Phihong USA PSAC12R-090-R-CR1	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug R/A	Wall Mount	Multi-Blade (Sold Separately)	100 mW	9 V	AS/NZS cULus IEC	1.33 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade	60950-1
Phihong USA PSAC12R-120	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	12 V	C-Tick CB CE cULus	1 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-075	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	7.5 V	C-Tick CB CE cULus	1.6 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-480	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	48 V	C-Tick CB CE cULus	250 mA	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-050	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	5 V	C-Tick CB CE cULus	2.4 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
Phihong USA PSAC12R-050-R-CR1	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug R/A	Wall Mount	Multi-Blade (Sold Separately)	100 mW	5 V	AS/NZS CCC cULus IEC PSE	2.4 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade	55022 60950-1 GB/T9254-2008 GB17625.1-2012 GB4943.1-2011
Phihong USA PSAC12R-090	12 W	International	264 VAC	90 VAC	10 mm	2.1 mm 5.5 mm	Barrel Plug	Wall Mount	Multi-Blade (Sold Separately)	100 mW	9 V	C-Tick CB CE cULus	1.33 A	ITE (Commercial)	Positive Center	40 °C	0 °C	2.82 in	71.7 mm	1.31 "	1.97 in	33.3 mm	50 mm	151.05 g	0.333 lb	1.5 m	59 in	CoC Tier 1 Level VI	Multi-Blade
