845-047 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 47POS 0.100
| Part | Material - Insulation | Termination Rows | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Read Out | Color | Flange Feature | Gender | Contact Material | Contact Finish | Contact Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Wire Wrap | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | 4-40 Threaded Insert Top Mount Opening | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder Eyelet(s) | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Side Mount Opening Unthreaded | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Flush Mount Side Opening Unthreaded | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Flush Mount Top Opening Unthreaded | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Side Mount Opening Unthreaded | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Wire Wrap | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Floating Bobbin Flush Mount | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Wire Wrap | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Through Hole | 0.25 Ám | 10 Áin | 1 | Wire Wrap | 125 °C | -40 C | Non Specified - Single Edge | Single | Green | Flush Mount M3 Threaded Insert Top Opening | Female | Copper Alloy | Gold | Cantilever | 47 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 47 | 0.1 " | 2.54 mm |
