A3-16PA Series

Catalog

CONN HEADER SMD 16POS 2MM

Part	Mated Stacking Heights [z]	Contact Finish Thickness - Post	Number of Rows [custom]	Shrouding	Fastening Type	Number of Positions Loaded	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Number of Positions	Style	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Contact Material	Contact Type	Insulation Height	Insulation Height	Termination	Contact Shape	Contact Finish - Mating	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Insulation Material	Contact Length - Mating	Contact Length - Mating	Connector Type	Insulation Color
Hirose Electric Co Ltd A3-16PA-2SV(71)	6 mm 8.8 mm	Flash	2	Unshrouded	Push-Pull	All	Gold	0.079 "	2 mm	16	Board to Board Cable	8 µin	0.203 µm	2 mm	0.079 in	Surface Mount	Brass	Male Pin	1.8 mm	0.071 in	Solder	Square	Gold	200 V	-55 C	85 °C	UL94 V-0	Polyphenylene Sulfide (PPS)	3.5 mm	0.138 in	Header	Brown
Hirose Electric Co Ltd A3-16PA-2SV	6 mm 8.8 mm		2	Unshrouded	Push-Pull	All		0.079 "	2 mm	16	Board to Board Cable			2 mm	0.079 in	Surface Mount	Brass	Male Pin	1.8 mm	0.071 in	Solder	Square	Gold	200 V	-55 C	85 °C	UL94 V-0	Polyphenylene Sulfide (PPS)	3.5 mm	0.138 in	Header	Brown
