TMPW 5 Series
Manufacturer: Traco Power
Beta
⌘K
AC/DC CONVERTER 24V 5W
| Part | Minimum Load Required | Standard Number | Voltage - Output 1 | Approval Agency | Current - Output 1 | Voltage - Input [Max] | Voltage - Input [Min] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Mounting Type | Type | Efficiency | Applications | Voltage - Isolation | Power (Watts) | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | 60335-1 62368-1 | 24 V | CB cURus | 210 mA | 250 VDC 305 VAC | 90 VAC 100 V | 43.2 mm | 2.17 " | 23.1 mm | 55.1 mm | 1.7 in | 0.91 in | Chassis Mount | Enclosed | 83 % | Household Appliances ITE (Commercial) | 4000 V | 5 W | 1 | |
Traco Power | 60335-1 62368-1 | 12 V | CB cURus | 420 mA | 250 VDC 305 VAC | 90 VAC 100 V | 43.2 mm | 2.17 " | 23.1 mm | 55.1 mm | 1.7 in | 0.91 in | Chassis Mount | Enclosed | 81 % | Household Appliances ITE (Commercial) | 4000 V | 5 W | 1 |
