1011632 Series
Manufacturer: Integrated Power Designs
Beta
⌘K
CE-225-4101CO
| Part | Voltage - Output 3 | Standard Number | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Output 4 | Features | Power (Watts) | Current - Output 2 | Current - Output 1 | Efficiency | Type | Approval Agency | Current - Output 3 | Current - Output 4 | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Outputs | Applications | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Integrated Power Designs | 12 V | 60601-1; 62368-1 | 5 V | 120.7 mm | 8 in | 203.2 mm | 55.1 mm | 4.75 " | 2.17 in | -12 V | Adjustable Output Remote Sense Universal Input | 225 W | 8 A | 25 A | 74 % | Enclosed | CE cURus TUV UKCA | 2 A | 2 A | 70 °C | 0 °C | Chassis Mount | 4 | ITE (Commercial) Medical | 24 V |
