PIC16LC771 Series

Catalog

MCU 8-BIT PIC16 PIC RISC 7KB EPROM 5V 20-PIN PDIP TUBE

Part	Core Size	Program Memory Size	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Number of I/O	Core Processor	Speed	Program Memory Type	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	RAM Size	Data Converters	Package / Case	Package / Case	Package / Case	Supplier Device Package	Connectivity	Oscillator Type	Package / Case [y]	Package / Case [y]
Microchip Technology PIC16C771-E/P	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	125 °C	Through Hole	256 x 8	6 channels 12 b	20-DIP	7.62 mm	0.3 in	20-PDIP	I2C SPI	Internal
Microchip Technology PIC16LC771T/SS	8-Bit	7 KB	5.5 V	2.5 V	15	PIC	20 MHz	OTP	0 °C	70 °C	Surface Mount	256 x 8	6 channels 12 b	20-SSOP			20-SSOP	I2C SPI	Internal
Microchip Technology PIC16C771-I/P	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	85 °C	Through Hole	256 x 8	6 channels 12 b	20-DIP	7.62 mm	0.3 in	20-PDIP	I2C SPI	Internal
Microchip Technology PIC16C771T/SO	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	0 °C	70 °C	Surface Mount	256 x 8	6 channels 12 b	20-SOIC			20-SOIC	I2C SPI	Internal	0.295 in	7.5 mm
Microchip Technology PIC16C771T-E/SO	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	125 °C	Surface Mount	256 x 8	6 channels 12 b	20-SOIC			20-SOIC	I2C SPI	Internal	0.295 in	7.5 mm
Microchip Technology PIC16C771T-I/SO	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	85 °C	Surface Mount	256 x 8	6 channels 12 b	20-SOIC			20-SOIC	I2C SPI	Internal	0.295 in	7.5 mm
Microchip Technology PIC16C771/SS	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	0 °C	70 °C	Surface Mount	256 x 8	6 channels 12 b	20-SSOP			20-SSOP	I2C SPI	Internal
Microchip Technology PIC16C771T-I/SS	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	85 °C	Surface Mount	256 x 8	6 channels 12 b	20-SSOP			20-SSOP	I2C SPI	Internal
Microchip Technology PIC16C771T-E/SS	8-Bit	7 KB	5.5 V	4 V	15	PIC	20 MHz	OTP	-40 °C	125 °C	Surface Mount	256 x 8	6 channels 12 b	20-SSOP			20-SSOP	I2C SPI	Internal
Microchip Technology PIC16LC771T/SO	8-Bit	7 KB	5.5 V	2.5 V	15	PIC	20 MHz	OTP	0 °C	70 °C	Surface Mount	256 x 8	6 channels 12 b	20-SOIC			20-SOIC	I2C SPI	Internal	0.295 in	7.5 mm

Catalog

Key Features

• * Programmable BOR

• Programmable LVD

• On-chip bandgap voltage reference

• Master mode I2C™Compatible

• Half-Bridge & Full-Bridge PWM with deadband control

• dual speed INTRC oscillator (4 MHz/37 kHz)

Description

This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS OTP-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 20-pin package and is upwards compatible with the PIC16C5X and PIC12CXXX devices. The PIC16C771 features 6 channels of 12-bit Analog-to-Digital (A/D) converter giving designers the ability to discriminate smaller signal changes and eliminate the need for external circuitry for high precision measurement of analog signals. With 2 additional timers and an enhanced capture/compare/PWM function that make it ideal for the most sophisticated applications requiring higher levels of A/D in automotive, industrial, appliances and consumer applications.
