A3A-10PA Series

Catalog

CONN HEADER SMD 10POS 2MM

Part	Contact Finish Thickness - Post	Mated Stacking Heights [z]	Row Spacing - Mating	Row Spacing - Mating	Termination	Contact Type	Operating Temperature [Min]	Operating Temperature [Max]	Shrouding	Contact Length - Mating	Contact Length - Mating	Fastening Type	Insulation Height	Insulation Height	Contact Material	Style	Number of Positions	Insulation Material	Connector Type	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Insulation Color	Material Flammability Rating	Features	Number of Rows [custom]	Pitch - Mating	Pitch - Mating	Mounting Type	Voltage Rating	Contact Shape	Number of Positions Loaded
Hirose Electric Co Ltd A3A-10PA-2SV(71)	Flash	6 mm 8.8 mm	2 mm	0.079 in	Solder	Male Pin	-55 C	85 °C	Unshrouded	3.5 mm	0.138 in	Push-Pull	1.8 mm	0.071 in	Brass	Board to Board Cable	10	Polyphenylene Sulfide (PPS)	Header	Gold	8 µin	0.203 µm	Gold	Brown	UL94 V-0	Board Guide	2	0.079 "	2 mm	Surface Mount	200 V	Square	All
Hirose Electric Co Ltd A3A-10PA-2SV(97)	Flash	6 mm 8.8 mm	2 mm	0.079 in	Solder	Male Pin	-55 C	85 °C	Unshrouded	3.5 mm	0.138 in	Push-Pull	1.8 mm	0.071 in	Brass	Board to Board Cable	10	Polyphenylene Sulfide (PPS)	Header	Gold			Gold	Brown	UL94 V-0	Board Guide	2	0.079 "	2 mm	Surface Mount	200 V	Square	All
Hirose Electric Co Ltd A3A-10PA-2SV(53)
Hirose Electric Co Ltd A3A-10PA-2SV		6 mm 8.8 mm	2 mm	0.079 in	Solder	Male Pin	-55 C	85 °C	Unshrouded	3.5 mm	0.138 in	Push-Pull	1.8 mm	0.071 in	Brass	Board to Board Cable	10	Polyphenylene Sulfide (PPS)	Header				Gold	Brown	UL94 V-0	Board Guide	2	0.079 "	2 mm	Surface Mount	200 V	Square	All
