TIW 12 Series
Manufacturer: Traco Power
Beta
⌘K
AC/DC CONVERTER 12V 12W
| Part | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output 1 | Power (Watts) | Voltage - Output 1 | Voltage - Input [Max] | Voltage - Input [Min] | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Approval Agency | Efficiency | Number of Outputs | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | Household Appliances ITE (Commercial) | 50 °C | -25 °C | 1 A | 12 W | 12 V | 264 VAC 375 VDC | 90 VAC 130 VDC | Chassis Mount | 2.17 " | 0.93 in | 48 mm | 55 mm | 23.6 mm | 1.89 in | CB cCSAus CE | 80 % | 1 | Enclosed |
Traco Power | Household Appliances ITE (Commercial) | 50 °C | -25 °C | 500 mA | 12 W | 24 V | 264 VAC 375 VDC | 90 VAC 130 VDC | Chassis Mount | 2.17 " | 0.93 in | 48 mm | 55 mm | 23.6 mm | 1.89 in | CB cCSAus CE | 80 % | 1 | Enclosed |
