AZ576-1C Series
Manufacturer: American Zettler
Beta
⌘K
RELAY GEN PURPOSE SPDT 20A 12V
| Part | Coil Resistance | Operate Time | Coil Type | Mounting Type | Termination Style | Relay Type | Coil Insulation | Approval Agency | Contact Form | Coil Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Must Release Voltage | Seal Rating | Release Time | Switching Voltage [Max] | Coil Current | Contact Rating (Current) | Must Operate Voltage | Load - Max Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 American Zettler | 360 Ohms | 15 ms | Non Latching | Through Hole | PC Pin | General Purpose | Class F | CUR TUV UL | SPDT (1 Form C) | 12 VDC | -40 C | 105 ░C | Silver Tin Oxide (AgSnO) | 1.2 VDC | Sealed - Fully | 8 ms | 30 VDC 480 VAC | 33.3 mA | 20 A | 9 VDC | 510 W 5540 VA |
 American Zettler | 810 Ohms | 15 ms | Non Latching | Through Hole | PC Pin | General Purpose | Class F | CUR TUV UL | SPDT (1 Form C) | 18 VDC | -40 C | 105 ░C | Silver Tin Oxide (AgSnO) | 0.9 VDC | Sealed - Flux Protection | 8 ms | 30 VDC 277 VAC | 22.2 mA | 20 A | 13.5 VDC | 510 W 5540 VA |
American Zettler | 1440 Ohms | 15 ms | Non Latching | Through Hole | PC Pin | General Purpose | Class F | CUR TUV UL | SPDT (1 Form C) | 24 VDC | -40 C | 105 ░C | Silver Tin Oxide (AgSnO) | 2.4 VDC | Sealed - Fully | 8 ms | 30 VDC 480 VAC | 16.7 mA | 20 A | 18 VDC | 510 W 5540 VA |
