H3LIS200DL Series

Ultra low power 3-axis accelerometer, SPI/I2C digital output MEMS motion sensor, user-selectable full scales of ±100g/±200g

Manufacturer: STMicroelectronics

Catalog

Ultra low power 3-axis accelerometer, SPI/I2C digital output MEMS motion sensor, user-selectable full scales of ±100g/±200g

Part	Output Type	Bandwidth [Min]	Bandwidth [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Type	Mounting Type	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Acceleration Range	Supplier Device Package	Axis [z]	Axis [y]	Axis [x]
STMicroelectronics H3LIS200DLTR	I2C SPI	25 Hz	500 Hz	85 °C	-40 C	Digital	Surface Mount	16-VFLGA	3.6 V	2.16 V	100 g 200 g	16-TFLGA (3x3)	Z	Y	X

Catalog

Ultra low power 3-axis accelerometer, SPI/I2C digital output MEMS motion sensor, user-selectable full scales of ±100g/±200g

Description

The H3LIS200DL is a low-power high-performance 3-axis linear accelerometer belonging to the "nano" family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power operational modes that allow advanced power saving and smart sleep-to-wakeup functions. The H3LIS200DL has dynamically user-selectable full scales of ±100g/±200g and is capable of measuring accelerations with output data rates from 0.5 Hz to 1 kHz. The H3LIS200DL is available in a small thin plastic land grid array package (LGA) and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.
