C3524 Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE COAX PLEN RG-6 18AWG 1000'
| Part | Jacket (Insulation) Material | Usage | Length | Length | Shield Type | Jacket Color | Cable Group | Cable Type | Wire Gauge | Length [x] | Length [x] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Impedance | Conductor Strand | Conductor Material | Wire Gauge | Dielectric Material | Shield Material | Shield Coverage [custom] | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | VoP, Velocity of Propagation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | Poly-Vinyl Chloride (PVC) | RF Signal Video | 100 ' | 30.48 m | Braid Foil | Natural | RG-6 | Coaxial - Plenum | 18 AWG | 15.24 m 304.8 m | 50 ft 1000 ft | 5.74 mm | 0.226 in | 75 Ohms | Solid | ||||||||
Prysmian Group | Poly-Vinyl Chloride (PVC) | RF Signal Video | 100 ' | 30.48 m | Braid Foil | Natural | RG-6 | Coaxial - Plenum | 0.82 mm² 18 AWG | 15.24 m 304.8 m | 50 ft 1000 ft | 5.74 mm | 0.226 in | 75 Ohms | Solid | Copper Coated Steel | 18 AWG | Fluoropolymer (FP) | Aluminum Flexfoil® | 60 % 100 % | 4.32 mm | 0.17 in | 85 |
