SPC58 Series

Socketed mini module for SPC58 2B, 4B and C lines in eTQFP64 package

Catalog

Socketed mini module for SPC58 2B, 4B and C lines in eTQFP64 package

Part	Board Type	Contents	Type	Utilized IC / Part	Oscillator Type	Core Size	Core Size	Peripherals	Connectivity	Mounting Type	Package / Case	RAM Size	Program Memory Size	Speed	Voltage - Supply (Vcc/Vdd)	Core Processor	Program Memory Type	Number of I/O	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	EEPROM Size	EEPROM Size	Qualification	Grade	RAM Size [custom]	RAM Size [custom]	Suggested Programming Environment	Interconnect System	Platform	Number of I/O [custom]	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Data Converters	Data Converters [Min]	Data Converters [Max]
STMicroelectronics SPC58XINT144EMU	Evaluation Platform	Board(s)	MCU 32-Bit	SPC58
STMicroelectronics SPC58EC80C3QMC0Y					Internal	32 Bit	Dual-Core	DMA	CANbus Ethernet FlexRay I2C LINbus SPI	Surface Mount	292-BGA	512 K	4 MB	180 MHz	3.3 V 5 V	e200z420	FLASH	64	292-LFBGA (17x17)	125 °C	-40 C	128 K
STMicroelectronics SPC58NG84E7QXC0Y					Internal	32 Bit	Tri-Core	DMA WDT	CANbus Ethernet FlexRay I2C LINbus SPI	Surface Mount	176-LQFP Exposed Pad		6 MB	180 MHz	3.3 V 5 V	e200z4	FLASH	64	176-eLQFP (24x24)	150 °C	-40 °C		256 x 8	AEC-Q100	Automotive	8	768
STMicroelectronics SPC58NG80E5QEC0X					Internal	32 Bit	Tri-Core	DMA WDT	CANbus Ethernet FlexRay I2C LINbus SPI	Surface Mount	144-TQFP Exposed Pad		4 MB	180 MHz	3.3 V 5 V	e200z4	FLASH	64	144-eTQFP (20x20)	150 °C	-40 °C		256 x 8	AEC-Q100	Automotive	8	768
STMicroelectronics SPC58EC-DISP	Evaluation Platform	Board(s)	MCU 32-Bit	SPC58EC80						Fixed																		SPC5Studio	Arduino R3 Shield	Discovery
STMicroelectronics SPC58XXADPT176S		Board(s)	MCU 32-Bit	SPC58xE/G
STMicroelectronics SPC58EEMU		Board(s)	MCU 32-Bit	SPC58						Fixed
STMicroelectronics SPC58EC80E3QMC0X					Internal	32 Bit	Dual-Core	DMA	CANbus I2C LINbus SPI	Surface Mount	100-TQFP Exposed Pad	512 K	4 MB	180 MHz	3.3 V 5 V	e200z420	FLASH		100-eTQFP (14x14)	125 °C	-40 °C	128 K		AEC-Q100	Automotive						80
STMicroelectronics SPC58EC80E7QMC0Y					Internal	32 Bit	Dual-Core	DMA	CANbus Ethernet FlexRay I2C LINbus SPI	Surface Mount	176-LQFP Exposed Pad	512 K	4 MB	180 MHz	3.3 V 5 V	e200z420	FLASH	64	176-eLQFP (24x24)	125 °C	-40 C	128 K
STMicroelectronics SPC58EG80E5QEC0X					External Internal	32 Bit	Dual-Core	DMA POR WDT	CANbus Ethernet FlexRay I2C LINbus SPI	Surface Mount	144-TQFP Exposed Pad	768 K	4 MB	180 MHz		e200z4	FLASH	120	144-eTQFP (20x20)	150 °C	-40 °C	256 K		AEC-Q100	Automotive							1.26 V	1.14 V	A/D SAR	10 b	12 b

Catalog

Socketed mini module for SPC58 2B, 4B and C lines in eTQFP64 package

Description

The SPC58XXADPT176S Premium Evaluation Boards System supports the 32-bit SPC58EE84E7, SPC58NE84E7, SPC58EN84E7, SPC58EG84E7 and SPC58NG84E7 STMicroelectronics' automotive microcontrollers. The complete system consists of an SPC58XXMB motherboard and an SPC58XXADPT176S daughter card which plugs into the motherboard. Different daughter cards are available for evaluating the whole family of device in all supported packages. All daughter cards are similar in design and concept. The evaluation system (motherboard and daughter card) allows full access to the CPU, all the CPU's I/O signals, and the motherboard peripherals (such as CAN, SCI, LIN and FlexRAY). The daughter card itself can be used as a standalone unit when access to the I/O pins or peripherals is not needed. The MCU is not included, it must be purchased separately. Please contact your sales representative for more details.
