Milli-Grid Header, Surface Mount, Vertical, 12 Circuits, 0.38µm Gold (Au) Selective Plating, with Press-fit Plastic Pegs, Lead-Free
Milli-Grid Header, Surface Mount, Vertical, 12 Circuits, 0.38µm Gold (Au) Selective Plating, with Press-fit Plastic Pegs, Lead-Free
Milli-Grid Header, Surface Mount, Vertical, 12 Circuits, 0.38µm Gold (Au) Selective Plating, with Press-fit Plastic Pegs, Lead-Free
| Part | Fastening Type | Contact Type | Insulation Color | Contact Finish - Mating | Contact Shape | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Pitch - Mating [x] | Pitch - Mating [x] | Number of Positions Loaded | Contact Material | Insulation Material | Mounting Type | Connector Type | Insulation Height | Insulation Height | Style | Row Spacing - Mating | Row Spacing - Mating | Termination | Contact Length - Mating | Contact Length - Mating | Contact Finish - Post | Applications | Shrouding | Number of Rows | Material Flammability Rating | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Push-Pull | Male Pin | Black | Gold | Square | Board Guide | 15 µin | 0.38 µm | 0.079 in | 2 mm | All | Phosphor Bronze | Thermoplastic | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 | 14 |
 Molex | Push-Pull | Male Pin | Black | Gold | Square | 30 Áin | 0.76 Ám | 0.079 in | 2 mm | All | Phosphor Bronze | Nylon Polyamide (PA) | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 | 20 | |
Molex | Push-Pull | Male Pin | Black | Gold | Square | Board Guide | 15 µin | 0.38 µm | 0.079 in | 2 mm | All | Phosphor Bronze | Thermoplastic | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 | 38 |
Molex | Push-Pull | Male Pin | Black | Gold | Square | Board Guide | 15 µin | 0.38 µm | 0.079 in | 2 mm | All | Phosphor Bronze | Thermoplastic | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 | 18 |
Molex | Push-Pull | Male Pin | Black | Gold | Square | Board Guide | 15 µin | 0.38 µm | 0.079 in | 2 mm | All | Phosphor Bronze | Thermoplastic | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 | 22 positions |
Molex | Push-Pull | Male Pin | Black | Gold | Square | Board Guide | 15 µin | 0.38 µm | 0.079 in | 2 mm | All | Phosphor Bronze | Thermoplastic | Surface Mount | Breakaway Header | 1.5 mm | 0.059 " | Board to Board Cable | 0.079 in | 2 mm | Solder | 0.15 in | 3.81 mm | Tin | Automotive General Purpose Telecommunications | Unshrouded | 2 | UL94 V-0 |
