BSC012 Series
Manufacturer: INFINEON
Beta
⌘K
OPTIMOS™ POWER MOSFET 60 V IN SUPERSO8 PACKAGE
| Part | Input Capacitance (Ciss) (Max) @ Vds [Max] | Drive Voltage (Max Rds On, Min Rds On) | FET Type | Vgs (Max) | Technology | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package | Package / Case | Current - Continuous Drain (Id) @ 25°C | Vgs(th) (Max) @ Id | Power Dissipation (Max) [Max] | Rds On (Max) @ Id, Vgs | Mounting Type | Gate Charge (Qg) (Max) @ Vgs [Max] | Drain to Source Voltage (Vdss) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 11000 pF | 6 V 10 V | N-Channel | 20 V | MOSFET (Metal Oxide) | 175 °C | -55 °C | PG-TSON-8-3 | 8-PowerTDFN | 36 A 306 A | 3.3 V | 214 W | 1.2 mOhm | Surface Mount | 143 nC | 60 V |
