35M048 Series
Manufacturer: Portescap
Beta
⌘K
STEPPER MOTOR PM UNIPOLAR 5V
| Part | Weight [custom] | Weight [custom] | Rotor Inertia | Voltage - Rated | Features | Mounting Hole Spacing [custom] | Mounting Hole Spacing [custom] | Coil Type | Type | Accuracy | Operating Temperature [Min] | Operating Temperature [Max] | Length - Shaft and Bearing | Length - Shaft and Bearing | Size / Dimension [diameter] | Size / Dimension [diameter] | Step Angle | Current Rating (Amps) | Torque - Holding (oz-in / mNm) | Torque - Holding (oz-in / mNm) | Coil Resistance | Termination Style | Diameter - Shaft [diameter] | Diameter - Shaft [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Portescap | 88 g | 0.194 lb | 2 gcm˛ | 5 V | Round Shaft | 42 mm | 1.65 in | Unipolar | Permanent Magnet | 15 % | -20 ░C | 70 °C | 0.445 in | 11.3 mm | 1.42 in | 35.94 mm | 7.5 ° | 400 mA | 18.35 mNm | 2.6 oz-in | 12.5 Ohms | Wire Leads | 0.079 in | 2 mm |
 Portescap | 88 g | 0.194 lb | 2 gcm˛ | 12 VDC | Round Shaft | 42 mm | 1.65 in | Unipolar | Permanent Magnet | 15 % | -20 ░C | 70 °C | 0.445 in | 11.3 mm | 1.42 in | 35.94 mm | 7.5 ° | 0.17 A | 18.35 mNm | 2.6 oz-in | 72 Ohms | Wire Leads | 0.079 in | 2 mm |
