DX10 Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
I/O CONNECTORS 2.54MM RA RECPT 28P THRU-HOLE GLD
| Part | Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Connector Type | Connector Style | Number of Rows [custom] | Flange Feature | Mounting Type | Contact Finish | Termination | Features | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Miniature High Density (HD) | 28 | 0.2 µm | 7.87 Áin | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) Latchblocks | Panel Mount Right Angle Through Hole | Gold | Solder | |||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 110 | 0.2 µm | 7.87 Áin | Receptacle | Outer Shroud Contacts | 2 | Panel Mount Right Angle Through Hole | Gold | Solder | Board Lock | |||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 68 positions | Receptacle | Outer Shroud Contacts | 2 | Panel Mount Right Angle Through Hole | Gold | Solder | ||||||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 28 | 0.2 µm | 7.87 Áin | Receptacle | Outer Shroud Contacts | 2 | Panel Mount Right Angle Through Hole | Gold | Solder | ||||
Hirose Electric Co Ltd | Miniature High Density (HD) | 14 | 0.3 Ám | 11.8 Áin | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) Latchblocks | Panel Mount Right Angle Through Hole | Gold | Solder | |||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 20 | 0.3 Ám | 11.8 Áin | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) | Panel Mount Right Angle Through Hole | Gold | Solder | |||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 50 | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) | Panel Mount Right Angle Through Hole | Gold | Solder | |||||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 14 | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) | Panel Mount Right Angle Through Hole | Gold | Solder | |||||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 80 | 0.2 µm | 7.87 Áin | Receptacle | Outer Shroud Contacts | 2 | Housing/Shell (M2.6) Latchblocks | Panel Mount Right Angle Through Hole | Gold | Solder | |||
 Hirose Electric Co Ltd | Miniature High Density (HD) | 20 | 0.3 Ám | 11.8 Áin | Receptacle | Outer Shroud Contacts | 2 | Panel Mount Right Angle Through Hole | Gold | Solder | Board Lock | Mating Side (M2.6) | Latchblocks |
