Surface Mount pHEMT 2 Watt Power Amplifier, 9 - 12 GHz
Key Features
• Saturated Power: +33 dBm @ 20% PAE
• Output IP3: +36 dBm
• Gain: 20 dB
• +7V @ 1300 mA Supply
• 50 Ω Matched Input/Output
• 25 mm2Leadless SMT Package
Description
AI
The HMC487LP5E is a high dynamic range GaAs PHEMT MMIC 2 Watt Power Amplifiers housed in leadless 5 x 5 mm surface mount packages. Operating from 9 to 12 GHz, the amplifier provides 20 dB of gain, +33 dBm of saturated power and 20% PAE from a +7V supply voltage. Output IP3 is +36 dBm typical. The RF I/Os are DC blocked and matched to 50 Ohms for ease of use. The HMC487LP5E eliminates the need for wire bonding, allowing use of surface mount manufacturing techniques.ApplicationsPoint-to-Point RadiosPoint-to-Multi-Point RadiosTest Equipment and SensorsMilitary End-Use
