845-005 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 5POS 0.100
| Part | Material - Insulation | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Number of Positions | Read Out | Number of Rows | Pitch | Pitch | Contact Material | Mounting Type | Flange Feature | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Card Type | Number of Positions/Bay/Row | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | 4-40 Threaded Insert Top Mount Opening | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Wire Wrap | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Side Mount Opening Unthreaded | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Wire Wrap | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.156 " | 3.96 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Wire Wrap | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Floating Bobbin Top Mount Opening | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Solder | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Wire Wrap | 5 | Single | 1 | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 5 | Green | 0.128 " | 3.25 mm |
