Switching Power Supplies
Switching Power Supplies
| Part | Minimum Load Required | Efficiency | Applications | Mounting Type | Power (Watts) | Number of Outputs | Voltage - Isolation | Features | Voltage - Input [Min] | Voltage - Input [Max] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Standard Number | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Type | Current - Output 1 | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | 88 % | ITE (Commercial) | Chassis Mount | 202 W | 1 | 3000 V | Adjustable Output PFC Universal Input | 85 VAC 120 VDC | 264 VAC 375 VDC | 115 mm | 30 mm | 4.53 " | 1.18 " | 212 mm | 8.35 " | 62368-1 | -30 °C | 70 °C | CB CE cURus | Enclosed | 8.4 A | 24 V | |
Traco Power | 89 % | ITE (Commercial) | Chassis Mount | 202 W | 1 | 3000 V | Adjustable Output PFC Universal Input | 85 VAC 120 VDC | 264 VAC 375 VDC | 115 mm | 30 mm | 4.53 " | 1.18 " | 212 mm | 8.35 " | 62368-1 | -30 °C | 70 °C | CB CE cURus | Enclosed | 4.2 A | 48 V | |
Traco Power | 86 % | ITE (Commercial) | Chassis Mount | 200 Watts | 1 | 3000 V | Adjustable Output PFC Universal Input | 85 VAC 120 VDC | 264 VAC 375 VDC | 115 mm | 30 mm | 4.53 " | 1.18 " | 212 mm | 8.35 " | 62368-1 | -30 °C | 70 °C | CB CE cURus | Enclosed | 16.7 A | 12 V |
