AM1DR Series
Manufacturer: aimtec
Beta
⌘K
DC DC CONVERTER 5V 1W
| Part | Applications | Type | Current - Output (Max) [Max] | Voltage - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Voltage - Input (Min) [Min] | Approval Agency | Number of Outputs | Efficiency | Voltage - Input (Max) [Max] | Package / Case | Voltage - Isolation | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | ITE (Commercial) | Isolated Module | 200 mA | 5 V | 85 °C | -40 C | Through Hole | 22.8 V | cULus cURus | 1 | 67 % | 25.2 V | 7-SIP Module | 3000 V | 0.37 in | 19.6 mm | 9.5 mm | 0.24 " | 0.77 in | 6 mm |
 aimtec | ITE (Commercial) | Isolated Module | 84 mA | 12 V | 85 °C | -40 C | Through Hole | 4.5 V | CE | 1 | 70 % | 5.5 V | 7-SIP Module | 1000 V | 0.39 " | 19.5 mm | 10 mm | 0.28 in | 0.76 " | 7.2 mm |
 aimtec | ITE (Commercial) | Isolated Module | 200 mA | 5 V | 85 °C | -40 C | Through Hole | 4.5 V | CE | 1 | 65 % | 5.5 V | 7-SIP Module 4 Leads | 1000 V | 0.39 " | 19.5 mm | 10 mm | 0.28 in | 0.77 in | 7.2 mm |
 aimtec | ITE (Commercial) | Isolated Module | 111 mA | 9 V | 85 °C | -40 C | Through Hole | 10.8 V | CE | 1 | 67 % | 13.2 V | 7-SIP Module | 1000 V | 0.39 " | 19.5 mm | 10 mm | 0.28 in | 0.76 " | 7.2 mm |
aimtec | ITE (Commercial) | Isolated Module | 200 mA | 5 V | 85 °C | -40 °C | Through Hole | 4.75 V | 1 | 67 % | 5.25 V | 7-SIP Module 4 Leads | 1000 V | 0.4 " | 19.6 mm | 10.2 mm | 0.24 " | 0.77 in | 6 mm | |
 aimtec | ITE (Commercial) | Isolated Module | 67 mA | 15 V | 85 °C | -40 C | Through Hole | 4.75 V | cULus cURus | 1 | 73 % | 5.25 V | 7-SIP Module | 3000 V | 0.38 in | 19.7 mm | 10.2 mm | 0.24 " | 0.77 in | 6 mm |
aimtec | ITE (Commercial) | Isolated Module | 200 mA | 5 V | 85 °C | -40 C | Through Hole | 10.8 V | CE | 1 | 63 % | 13.2 V | 7-SIP Module | 1000 V | 0.39 " | 19.5 mm | 10 mm | 0.28 in | 0.76 " | 7.2 mm |
aimtec | ITE (Commercial) | Isolated Module | 111 mA | 9 V | 85 °C | -40 C | Through Hole | 4.75 V | cULus cURus | 1 | 71 % | 5.25 V | 7-SIP Module | 3000 V | 0.38 in | 19.7 mm | 10.2 mm | 0.24 " | 0.77 in | 6 mm |
aimtec | ITE (Commercial) | Isolated Module | 303 mA | 3.3 V | 85 °C | -40 C | Through Hole | 10.8 V | CE | 1 | 61 % | 13.2 V | 7-SIP Module | 1000 V | 0.39 " | 19.5 mm | 10 mm | 0.28 in | 0.76 " | 7.2 mm |
 aimtec | ITE (Commercial) | Isolated Module | 200 mA | 5 V | 85 °C | -40 °C | Through Hole | 4.75 V | 1 | 70 % | 5.25 V | 7-SIP Module 5 Leads | 3000 V | 0.38 in | 19.6 mm | 9.7 mm | 0.24 " | 0.77 in | 6 mm |
