AZ943-1C Series
Manufacturer: American Zettler
Beta
⌘K
RELAY GEN PURPOSE SPDT 10A 12V
| Part | Coil Resistance | Contact Rating (Current) | Switching Voltage [Max] | Coil Current | Coil Voltage | Relay Type | Load - Max Switching | Seal Rating | Termination Style | Must Operate Voltage | Operate Time | Contact Material | Mounting Type | Contact Form | Coil Insulation | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Must Release Voltage | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 American Zettler | 400 Ohms | 10 A | 30 VDC 277 VAC | 0.03 A | 12 VDC | General Purpose | 300 W 2770 VA | Sealed - Flux Protection | PC Pin | 9 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 1.2 VDC | 5 ms |
American Zettler | 400 Ohms | 10 A | 30 VDC 277 VAC | 0.03 A | 12 VDC | General Purpose | 300 W 2770 VA | Sealed - Fully | PC Pin | 9 VDC | 10 ms | Gold (Au) Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 1.2 VDC | 5 ms |
American Zettler | 70 Ohms | 10 A | 30 VDC 277 VAC | 71.4 mA | 5 VDC | General Purpose | 300 W 2770 VA | Sealed - Fully | PC Pin | 3.8 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class F | cUR TUV UL VDE | 110 °C | -40 C | Non Latching | 0.5 VDC | 5 ms |
American Zettler | 100 Ohms | 10 A | 30 VDC 277 VAC | 0.06 A | General Purpose | 300 W 2770 VA | Sealed - Flux Protection | PC Pin | 4.5 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 0.6 VDC | 5 ms | |
American Zettler | 6.4 kOhms | 10 A | 30 VDC 277 VAC | 7.5 mA | 48 VDC | General Purpose | 300 W 2770 VA | Sealed - Flux Protection | PC Pin | 36 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 4.8 VDC | 5 ms |
 American Zettler | 100 Ohms | 10 A | 30 VDC 277 VAC | 0.06 A | General Purpose | 300 W 2770 VA | Sealed - Fully | PC Pin | 4.5 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 0.6 VDC | 5 ms | |
 American Zettler | 1.6 kOhms | 10 A | 30 VDC 277 VAC | 0.015 A | 24 VDC | General Purpose | 300 W 2770 VA | Sealed - Fully | PC Pin | 18 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 2.4 VDC | 5 ms |
American Zettler | 900 Ohms | 10 A | 30 VDC 277 VAC | 0.02 A | 18 VDC | General Purpose | 300 W 2770 VA | Sealed - Flux Protection | PC Pin | 13.5 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class F | cUR TUV UL VDE | 110 °C | -40 C | Non Latching | 1.8 VDC | 5 ms |
American Zettler | 400 Ohms | 10 A | 30 VDC 277 VAC | 0.03 A | 12 VDC | General Purpose | 300 W 2770 VA | Sealed - Fully | PC Pin | 9 VDC | 10 ms | Silver Tin Oxide (AgSnO) | Through Hole | SPDT (1 Form C) | Class B | cUR TUV UL VDE | 90 °C | -40 C | Non Latching | 1.2 VDC | 5 ms |
