Dual Die part consisting of a 100mA NBRT and 500mA PBRT
Description
AI
NPN and PNP Silicon Surface Mount Transistors with Monolithic Bias Resistor Network.
Beta
⌘K
Dual Die part consisting of a 100mA NBRT and 500mA PBRT
Dual Die part consisting of a 100mA NBRT and 500mA PBRT
| Part | DC Current Gain (hFE) (Min) @ Ic, Vce | Current - Collector (Ic) (Max) [Max] | Supplier Device Package | Resistor - Base (R1) | Current - Collector Cutoff (Max) [Max] | Power - Max [Max] | Vce Saturation (Max) @ Ib, Ic | Transistor Type | Voltage - Collector Emitter Breakdown (Max) [Max] | Mounting Type | Package / Case | Resistor - Emitter Base (R2) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ON Semiconductor | 68 100 | 500 mA | SC-74R | 13 kOhms 130 Ohms | 500 nA | 285 mW | 300 mV | 1 NPN 1 PNP | 50 V | Surface Mount | SC-74 SOT-457 | 10 kOhms |
