Thermoelectric Peltier Modules
Thermoelectric Peltier Modules
| Part | Features | Type | Operating Temperature | Qmax @ Th | Voltage - Max [Max] | Delta Tmax @ Th | Number of Stages | Size / Dimension [y] | Size / Dimension [x] | Current - Max [Max] | Resistance | Height [z] | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tark Thermal Solutions | Lead Wires Sealed - Epoxy | TEC (Thermoelectric Cooler) | 80 °C | 51.4 W | 14.5 V | 67 °C | 1 | 39.88 mm | 39.88 mm | 6 A | 2.25 Ohms | 3.81 mm | |
 Tark Thermal Solutions | Lead Wires Sealed - Silicone RTV | TEC (Thermoelectric Cooler) | 80 °C | 68.4 W | 8.1 V | 67 °C | 1 | 43.94 mm | 43.94 mm | 14.3 A | 530 mOhms | 4.57 mm | |
 Tark Thermal Solutions | Lead Wires Sealed - Epoxy | TEC (Thermoelectric Cooler) | 80 °C | 20.4 W | 4 V | 68 °C | 1 | 14.86 mm | 29.72 mm | 8.7 A | 430 mOhms | 3.33 mm | |
 Tark Thermal Solutions | Lead Wires Sealed - Silicone RTV | TEC (Thermoelectric Cooler) | 80 °C | 25.7 W | 14.5 V | 68 °C | 1 | 29.72 mm | 29.72 mm | 3 A | 4.35 Ohms | 3.61 mm | |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 1 | |||||||||||
 Tark Thermal Solutions | Lead Wires Sealed - Silicone RTV | TEC (Thermoelectric Cooler) | 80 °C | 79.2 W | 18.4 V | 67 °C | 1 | 39.88 mm | 39.88 mm | 7.3 A | 2.33 Ohms | 3.2 mm | |
 Tark Thermal Solutions | Lead Wires Non-Sealed | TEC (Thermoelectric Cooler) | 80 °C | 18.8 W | 3.8 V | 67 °C | 1 | 29.72 mm | 29.72 mm | 9 A | 350 mOhms | 5.59 mm | |
 Tark Thermal Solutions | Lead Wires Sealed - Epoxy | TEC (Thermoelectric Cooler) | 80 °C | 8.2 W | 3.8 V | 67 °C | 1 | 15 mm | 15 mm | 3.9 A | 820 mOhms | 3.2 mm | |
 Tark Thermal Solutions | Lead Wires Non-Sealed | TEC (Thermoelectric Cooler) | 80 °C | 20 W | 14.5 V | 68 °C | 1 | 29.72 mm | 29.72 mm | 2.3 A | 5.76 Ohms | 3.58 mm | |
 Tark Thermal Solutions | Lead Wires Sealed - Epoxy | TEC (Thermoelectric Cooler) | 80 °C | 34.3 W | 14.4 V | 67 °C | 1 | 29.7 mm | 29.7 mm | 3.9 A | 3.36 Ohms | 3.2 mm |
