PIC16F527 Series

Catalog

1.5KB FLASH PROGRAM, 64B FLASH DATA, 8MHZ INTERNAL OSCILLATOR, 8B ADC, 2X COMPARATORS, 2X OP AMPS 20 UQFN 3X3X0.5MM TUBE ROHS CO

Part	Speed	Supplier Device Package	RAM Size	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Oscillator Type	Core Size	EEPROM Size [custom]	EEPROM Size [custom]	Mounting Type	Program Memory Size	Core Processor	Package / Case	Program Memory Type	Data Converters	Number of I/O	Package / Case	Package / Case	Package / Case [y]	Package / Case [y]
Microchip Technology PIC16F527-E/JP	20 MHz	20-UQFN	68 x 8	-40 °C	125 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-UFQFN Exposed Pad	FLASH	A/D 8x8b	17
Microchip Technology PIC16F527T-I/SS	20 MHz	20-SSOP	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-SSOP	FLASH	A/D 8x8b	17
Microchip Technology PIC16F527-E/ML	20 MHz	20-QFN (4x4)	68 x 8	-40 °C	125 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-VFQFN Exposed Pad	FLASH	A/D 8x8b	17
Microchip Technology PIC16F527-E/P	20 MHz	20-PDIP	68 x 8	-40 °C	125 °C	5.5 V	2 V	Internal	8-Bit	8	64	Through Hole	1.5 KB	PIC	20-DIP	FLASH	A/D 8x8b	17	7.62 mm	0.3 in
Microchip Technology PIC16F527-I/SO	20 MHz	20-SOIC	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-SOIC	FLASH	A/D 8x8b	17			0.295 in	7.5 mm
Microchip Technology PIC16F527T-I/SO	20 MHz	20-SOIC	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-SOIC	FLASH	A/D 8x8b	17			0.295 in	7.5 mm
Microchip Technology PIC16F527-I/SS	20 MHz	20-SSOP	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-SSOP	FLASH	A/D 8x8b	17
Microchip Technology PIC16F527-I/P	20 MHz	20-PDIP	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Through Hole	1.5 KB	PIC	20-DIP	FLASH	A/D 8x8b	17	7.62 mm	0.3 in
Microchip Technology PIC16F527T-I/ML	20 MHz	20-QFN (4x4)	68 x 8	-40 °C	85 °C	5.5 V	2 V	Internal	8-Bit	8	64	Surface Mount	1.5 KB	PIC	20-VFQFN Exposed Pad	FLASH	A/D 8x8b	17

Catalog

Key Features

• * Two Hardware Interrupts

• * Four Stack levels

• * Flash Program Memory with self read/write capability

• * Internal 8MHz oscillator

• * Dual Op Amp Module with 3MHz GBWP

• * Dual Analog Comparator Module

• * 8 Channel 8 bit ADC

• * Brown-Out Reset (BOR)

• * On-board Watchdog Timer

• * One 8-bit Timer

• * 25mA Source/Sink current I/O

• * In Circuit Serial Programming (ICSP)

• * Low Standby Current: 100 nA @ 2.0V, typical

• * Wide Operating Voltage (2.0V – 5.5V)

• * eXtreme Low Power (XLP)

Description

The PIC16F527 combines the flexiblity of integrated Analog with the intelligence of a PIC® Microcontroller to create a low cost MCU suitable for a wide range of applications. With an on-board ADC, dual Op Amps, and two Comparators, the PIC16F527 offers an excellent solution for signal conditioning and sensing applications.
