HiTemp ETX Series
Thermoelectric Peltier Modules HiTemp ETX Series, Thermoelectric Cooler, RTV perimeter seal
Manufacturer: Tark Thermal Solutions
Catalog
Thermoelectric Peltier Modules HiTemp ETX Series, Thermoelectric Cooler, RTV perimeter seal
| Part | Type | Delta Tmax | Number of Stages | Features | Size / Dimension Shape | Size / Dimension Length | Size / Dimension Width | Current - Max | Voltage - Max | Operating Temperature | Resistance | Maximum Power Dissipation (Qmax) | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Rectangular | 26.9 mm | 24.6 mm | 7.9 A | 16.6 V | 150 °C | 1.95 Ohms | 77.8 W | 1.96 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 62 mm | 62 mm | 25 A | 16.6 V | 150 °C | 620 mOhms | 245.1 W | 4.1 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lapped Lead Wires | Rectangular | 25 mm | 12.5 mm | 2.6 A | 8.2 V | 150 °C | 2.94 Ohms | 12.7 W | 3.1 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lapped Lead Wires | Square | 25 mm | 25 mm | 2.1 A | 16.6 V | 150 °C | 7.35 Ohms | 20.6 W | 3.4 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 30 mm | 30 mm | 4 A | 16.6 V | 150 °C | 3.91 Ohms | 38.8 W | 3.2 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 30 mm | 30 mm | 11 A | 16.6 V | 150 °C | 1.4 Ohms | 108.2 W | 2.41 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 30 mm | 30 mm | 14.1 A | 4.1 V | 150 °C | 270 mOhms | 33.8 W | 2.41 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lapped Lead Wires | Square | 62 mm | 62 mm | 14.1 A | 16.6 V | 150 °C | 1.09 Ohms | 138.5 W | 4.6 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 40 mm | 40 mm | 3.9 A | 16.6 V | 150 °C | 4.01 Ohms | 37.8 W | 4.8 mm |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 83.2 °C | 1 | Lead Wires Sealed Silicone RTV | Square | 40 mm | 40 mm | 5.9 A | 26 V | 150 °C | 4.1 Ohms | 90.8 W | 3.91 mm |
