ACST10 Series

Catalog

TRIAC SENS GATE 700V 10A TO220

Part	Current - Gate Trigger (Igt) (Max) [Max]	Voltage - Gate Trigger (Vgt) (Max)	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Current - On State (It (RMS)) (Max) [Max]	Supplier Device Package	Current - Non Rep. Surge 50, 60Hz (Itsm)	Triac Type	Current - Hold (Ih) (Max) [Max]	Configuration	Mounting Type	Voltage - Off State
STMicroelectronics ACST10-7CT	10 mA	1 V	-40 C	125 °C	TO-220-3	10 A	TO-220	100 A 105 A	Logic - Sensitive Gate	30 mA	Single	Through Hole	700 V
STMicroelectronics ACST1010-7T	10 mA	1 V	-40 C	125 °C	TO-220-3	10 A	TO-220	100 A 105 A	Logic - Sensitive Gate	30 mA	Single	Through Hole	700 V
STMicroelectronics ACST10-7SFP	10 mA	1 V	-40 C	125 °C	TO-220-3 Full Pack	10 A	TO-220FP	100 A 105 A	Logic - Sensitive Gate	30 mA	Single	Through Hole	700 V
STMicroelectronics ACST10-7CFP	35 mA	1 V	-40 C	125 °C	TO-220-3 Full Pack	10 A	TO-220FP	100 A 105 A	Standard	50 mA	Single	Through Hole	700 V
