ADF4360-6 Series

Integrated Integer-N Synthesizer and VCO - Output Frequency 1450 to 1750

Catalog

Integrated Integer-N Synthesizer and VCO - Output Frequency 1450 to 1750

Part	Ratio - Input:Output [custom]	Frequency - Max [Max]	Divider/Multiplier	Voltage - Supply [Max]	Voltage - Supply [Min]	Output	Input	Type	Mounting Type	Supplier Device Package	Package / Case	Number of Circuits	Operating Temperature [Max]	Operating Temperature [Min]	Contents	Utilized IC / Part	Primary Attributes	Supplied Contents	Secondary Attributes	Function	Secondary Attributes
Analog Devices ADF4360-1BCPRL7	1:2	2.45 GHz	Yes/No	3.6 V	3 V	Clock	CMOS	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP
Analog Devices ADF4360-6BCPZRL7	1:2	1.25 GHz	Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C
Analog Devices ADF4360-0BCP	1:2	2.725 GHz	Yes/No	3.6 V	3 V	Clock	CMOS	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP
Analog Devices EV-ADF4360-8EB1Z								Timing							Board(s) Cable(s)	ADF4360-8	Single Integer-N PLL with VCO	Board(s) Cable(s)	Differential Output	Frequency Synthesizer
Analog Devices EV-ADF4360-7EB1Z								Timing							Board(s) Cable(s)	ADF4360-7	Single Integer-N PLL with VCO	Board(s) Cable(s)		Frequency Synthesizer	200 kHz 900 MHz
Analog Devices ADF4360-2BCPZ	1:2	2.17 GHz	Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C
Analog Devices ADF4360-3BCPZRL	1:2		Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C
Analog Devices ADF4360-2BCPZRL7	1:2	2.17 GHz	Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C
Analog Devices ADF4360-1BCPZRL7	1:2	2.45 GHz	Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C
Analog Devices ADF4360-3BCPZ	1:2		Yes/No	3.6 V	3 V	Clock	CMOS TTL	Fanout Distribution Integer N Synthesizer (RF)	Surface Mount	24-LFCSP (4x4)	24-WFQFN Exposed Pad CSP	1	85 °C	-40 °C

Catalog

Integrated Integer-N Synthesizer and VCO - Output Frequency 1450 to 1750

Key Features

• Output frequency range: 1450 MHz to 1750 MHz

• Divide-by-2 output

• 3.0 V to 3.6 V power supply

• 1.8 V logic compatibility

• Integer-N synthesizer

• Programmable dual-modulus prescaler 8/9, 16/17, 32/33

• Programmable output power level

• 3-wire serial interface

• Analog and digital lock detect

• Hardware and software power-down mode

Description

The ADF4360-9 is an integrated integer-N synthesizer and voltage controlled oscillator (VCO). The ADF4360-9 center frequency is set by external inductors. This allows a VCO frequency range of between 65 MHz and 400 MHz.An additional divider stage allows division of the VCO signal. The CMOS level output is equivalent to the VCO signal divided by integer value between 2 and 31. This divided signal can be further divided by two if desired.Control of all the on-chip registers is through a simple 3-wire interface. The device operates with a power supply ranging from 3.0 V to 3.6 V and can be powered down when not in use.ApplicationsSystem clock generationTest equipmentWireless LANsCATV equipmentData Sheet, Rev. A, 3/08
