SIZF914 Series
Manufacturer: Vishay General Semiconductor - Diodes Division
Beta
⌘K
MOSFET 2N-CH 25V 23.5A 8PWRPAIR
| Part | Input Capacitance (Ciss) (Max) @ Vds | Package / Case | Supplier Device Package | Technology | Rds On (Max) @ Id, Vgs | Power - Max | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Gate Charge (Qg) (Max) @ Vgs | Drain to Source Voltage (Vdss) | Mounting Type | Configuration | Current - Continuous Drain (Id) @ 25°C | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay General Semiconductor - Diodes Division | 1050 pF 4670 pF | 8-PowerWDFN | 8-PowerPair® (6x5) | MOSFET (Metal Oxide) | 0.9 mOhm 3.8 mOhm | 3.4 W 4 W 26.6 W 60 W | 2.2 V 2.4 V | 21 nC | 98 nC | 25 V | Surface Mount | 2 N-Channel (Dual) | 23.5 A 40 A 52 A 60 A | -55 °C | 150 °C |
