06015KA Series
Manufacturer: NMB TECHNOLOGIES
Beta
⌘K
DC FANS DC TUBEAXIAL FAN, 60X60X15MM, 24VDC, 14.1CFM, RIB MOUNT, LEAD WIRES
| Part | Width [y] | RPM | Termination | Noise | Fan Type | Features | Size / Dimension [z] | Size / Dimension [x] | Voltage - Rated | Air Flow | Air Flow | Bearing Type | Static Pressure | Static Pressure | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Material - Blade | Current Rating (Amps) | Voltage Range [Max] | Voltage Range [Min] | Lifetime @ Temp. | Material - Frame | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | 15 mm | 3600 RPM | 2 Wire Leads | 28 dB | Tubeaxial | Auto Restart | 60 mm | 60 mm | 24 VDC | 14.1 CFM | 0.395 m³/min | Ball | 32.4 Pa | 0.13 in H2O | -10 °C | 60 °C | 1.4 W | ||||||||
 NMB TECHNOLOGIES | 15 mm | 3600 RPM | 3 Wire Leads | 28 dB | Tubeaxial | Locked Rotor Sensor | 60 mm | 60 mm | 12 VDC | 14.1 CFM | 0.395 m³/min | Ball | 31.1 Pa | 0.125 in H2O | -10 °C | 60 °C | 1.08 W | Plastic | 0.09 A | 13.8 VDC | 6 VDC | 70000 Hrs | Plastic | 44.91 g | 0.099 lb |
 NMB TECHNOLOGIES | 15 mm | 3100 RPM | 3 Wire Leads | 25 dB(A) | Tubeaxial | Auto Restart Locked Rotor Sensor | 60 mm | 60 mm | 12 VDC | 11.6 CFM | 0.325 mł/min | Ball | 22.4 Pa | 0.09 in H2O | -10 °C | 60 °C | 840 mW | Plastic | 70 mA | 13.8 VDC | 6 VDC | 70000 Hrs | Plastic |
