846 Series
Manufacturer: EDAC Inc.
Beta
⌘K
STANDARD CARD EDGE CONNECTORS HIGH TEMP CARD EDGE CONNECTORS
| Part | Termination Rows | Material - Insulation | Contact Finish | Number of Positions | Number of Positions/Bay/Row | Mounting Type | Card Type | Read Out | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Rows | Contact Material | Gender | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features | Number of Rows [custom] | Number of Positions | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 47 | 47 | Through Hole | Non Specified - Single Edge | Single | Cantilever | 125 °C | -40 C | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Green | 1 | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | 14 | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Card Extender | 2 | 28 | ||||
 EDAC Inc. | Gold | 47 | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Card Extender | 2 | 94 | ||||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | 28 | Right Angle Through Hole | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | 56 | ||||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 30 | Right Angle Through Hole | Non Specified - Single Edge | Single | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | 1 | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 30 | ||||||||
 EDAC Inc. | Gold | 33 | Through Hole | Non Specified - Single Edge | Single | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | 1 | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 33 | |||||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | 26 | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.156 " | 3.96 mm | Card Extender | 2 | 52 | |||||
 EDAC Inc. | Gold | 30 | Through Hole | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 2 | 60 | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | 30 | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Card Extender | 2 | 60 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Gold | 39 | Through Hole | Non Specified - Dual Edge | Dual | Cantilever | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | Green | Copper Alloy | Female | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount M3 Threaded Insert Top Opening | 2 | 78 |
